CRANE Temper is a premium, ready-to-use organic salt based Heat Transfer Fluid specifically designed for diverse refrigeration applications. It stands out as a non-toxic and environmentally friendly product, offering excellent performance in various industrial settings. CRANE Tempers formulation includes a unique combination of salts that are readily biodegradable, making it an eco-conscious choice for businesses focused on sustainability.
ADVANTAGES WITH CRANE TEMPER?
This world class range, manufactured in Sweden, combines chemical stability with exceptional energy efficiency resulting in significant long term savings and sustainable outcomes. Unlike glycol based products,CRANE Temper will not degrade over time resultingin an exceptional long life span. CRANE Temper also has a high specific heat capacity (eg 3.3 kJ/kg+ K for CRANE Temper -20 C at 20 C) and outstanding thermal conductivity compared with propylene glycol. Since the viscosity of CRANE Temper is relatively low compared with glycol, pumps and pipe work can be smaller without compromising performance. This cuts cost of purchasing, installing and running the system. CRANE Temper can, due to the low viscosity, be used at low temperatures down to -60 C. It is available through out the world in seven different versions from -10 C to -60 C.
- Low viscosity
- High thermal conductivity
- Reduced energy cost
- Readily biodegradable
- Adapted for the food industry
- Advanced inhibitor technology
- Personalized technical support
HOW SAFE IS CRANE TEMPER?
CRANE Temper is an environmentally adapted heat transfer fluid which fulfills the highest environmental requirements. It is readily biodegradable, this means that 97% of the fluid will be consumed after 7 days compared to glycols where only 70 to 85% is consumed after 28 days. CRANE Temper is non-toxic and can be used in refrigerating plants within the food sector. It is neutral (pH 8-9) and does not require any special handling or storage. CRANE Temper contains no nitrates or phosphates and is classified as non-hazardous to health and the environment.
THERMOPHYSICAL PROPERTIES
|
Property |
Unit |
T-10 |
T-15 |
T-20 |
T-30 |
T-40 |
T-55 |
T-60 |
|
Density |
kg/m |
1086 |
1114 |
1142 |
1177 |
1207 |
1240 |
1260 |
|
Specific heat |
KJ/kg K |
3.577 |
3.447 |
3.315 |
3.124 |
3.012 |
2.817 |
2.820 |
|
Thermal conductivity |
W/m K |
0.544 |
0.525 |
0.508 |
0.486 |
0.465 |
0.441 |
0.440 |
|
Dynamic viscosity |
mPa s |
1.48 |
1.62 |
1.79 |
2.17 |
2.76 |
4.06 |
4.28 |
|
Kinematic viscosity |
mm/s |
1.37 |
1.45 |
1.57 |
1.84 |
2.29 |
3.27 |
3.40 |
AREAS OF USE
- FOOD INDUSTRY
- DISTRIBUTION LOGISTICS
- SUPERMARKETS
- DEFROSTING OF CO2 AIR COOLERS
- CLIMATE TEST CENTERS
- FUEL CELL/HYDROGEN TANKING STATION
- SPORTS INSTALLATIONS
HOW CAN CRANE TEMPER BE USED?
CRANE Temper can be used whenever a heat transfer fluid is required, in stationary or mobile installations for secondary refrigeration systems. CRANE Temper is suitable for medium as well as low temperature refrigeration systems and is effectively used at temperatures between -60 C up to +180 C in pressurized systems. CRANE Temper offers particular advantages as an alternative to glycol mixtures in the area of indirect cooling at low temperatures.
